Face Frame Cabinet CAD Core Pack
$39Overview
The Face Frame Cabinet CAD Core Pack is a structured collection of parametric reference models that show how I design traditional face-frame cabinets in Fusion 360 for real woodworking projects. These are clean, dimension-driven models built to be adapted to your materials, sizes, and construction standards, while maintaining consistent face-frame logic and reveals. The goal of this pack is to give you a repeatable face-frame cabinet system that reduces setup time and removes guesswork in CAD.
What’s Included (Face Frame Pack)
Base Cabinets
- Standard Base Cabinet (1 Drawer + Door)
- Three-Drawer Stack
- Base Cabinet with Full Doors
- Blind Base Corner (Left)
Upper Cabinets
- Upper Cabinet with Full Doors
- Upper Blind Corner (Left)
Tall Cabinets
- Tall with Double Oven
- Tall with Single Oven
- Tall with Full Doors (this model can be manipulated into many different door combinations)
Technical Notes & Usage
- Designed in Fusion 360 for CNC cabinet builds
- Files contain design models only (no CAM or manufacturing setups)
- Geometry is based around common cabinet tooling: 3/8", 5 mm, 1/8"
- Key parameters are included for modifying cabinet sizes and layouts
- An Excel file and PDF documenting adjustable parameters are included
- Files are fully editable Fusion 360 designs (no STL exports included)
Who This Is Not For
This pack is not intended for:
- Users looking for ready-to-run CNC toolpaths
- Anyone expecting STL files or import into other CAD systems
“These CAD models are designed to reduce setup time and thinking friction — not to replace your judgment as a builder.”
